Exact product identification
Your quotation references the complete manufacturer part number to keep the requested product clear.
SICK W4F V-Optics Photoelectric Sensor WTV4FE-213111A0ZZZ
WTV4FE-213111A0ZZZ
SICK WTV4FE-213111A0ZZZ W4F v-optics photoelectric sensor with Background suppression, V-optics, 2–22 mm sensing range, 1 push-pull pnp/npn output and m8 connector, 3-pin.
- Availability
- In Stock
- Condition
- New Original
- SKU
- 1120709
- Lifecycle
- Active
12 months warranty
Warranty coverage and terms are confirmed with your order.
Fast shipping
We coordinate the fastest available shipping option for your destination.
Secure payment
Available payment methods are handled through secure payment channels.
Worldwide delivery
Carrier and delivery options are confirmed for your destination before dispatch.
Independent supplier: Xindustra is not an authorized distributor, reseller, or representative of SICK. Brand names are used for identification and compatibility purposes only. Read disclaimer
Technical specifications
Verified SICK ordering and technical data for WTV4FE-213111A0ZZZ, SICK part number 1120709.
- Manufacturer type
WTV4FE-213111A0ZZZ
- SICK part number
1120709
- Brand
SICK
- Product family
W4F
- Product type
V-Optics Photoelectric Sensor
- Functional principle
Background suppression, V-optics
- Manufacturer lifecycle
Active
- Sensing range
2–22 mm
- Recommended operating range
Application-defined within 2–22 mm
- Light source
PinPoint LED, visible red light, 635 nm
- Light spot
Rectangular, 0.5 × 1.9 mm at 30 mm
- Documented application focus
transparent, reflective and very small objects at short range
- Supply voltage
10–30 V DC
- Current consumption
≤ 25 mA without load at 24 V
- Digital outputs
1 push-pull PNP/NPN output
- Switching mode
Light switching
- Maximum output current
100 mA
- Response time
≤ 500 µs
- Switching frequency
1,000 Hz
- Communication
Conventional switching output
- Connection
M8 connector, 3-pin
- Housing
Rectangular flat design, plastic VISTAL®
- Dimensions
16 × 40.1 × 12.1 mm
- Weight
Approx. 30 g
- Enclosure rating
IP66 and IP67
- Operating temperature
−40 to +60 °C
- Storage temperature
−40 to +75 °C
Confirm the sensing geometry, connection, output logic before installing WTV4FE-213111A0ZZZ.
M8 connector, 3-pin
Connection Use the official connection diagram and confirm conductor or pin assignments before wiring the device.
1 push-pull PNP/NPN output
Light switching Verify the required output logic and the downstream control input before commissioning.
Sensing range 2–22 mm
Background suppression, V-optics Apply the manufacturer operating-range and target/background guidance; the recommended range is Application-defined within 2–22 mm.
Background suppression, V-optics
Optical geometry This variant is intended for transparent, reflective and very small objects at short range. Confirm target behavior and mounting geometry in the application.
Selection and replacement checks
Do not substitute another W4F type solely because the housing looks the same. Verify the full type code, numeric SICK part number, optics, output behavior and connection.
Downloads and documentation
Use current SICK documentation for wiring, configuration and application checks.
Sourcing and order support
Order the exact product and condition your project requires, with assistance from quotation through delivery.
Condition options
Tell us whether you need new original, new surplus, used, refurbished or repaired equipment.
International delivery
Shipping options are prepared around your destination, quantity and requested delivery date.
Documentation support
Access available manufacturer product data, manuals and certificates associated with the order number.
WTV4FE-213111A0ZZZ questions
Answers to common identification and integration questions for this exact sensor.
What is the SICK part number for WTV4FE-213111A0ZZZ?
SICK lists numeric part number 1120709 for type WTV4FE-213111A0ZZZ.
What sensing principle does WTV4FE-213111A0ZZZ use?
WTV4FE-213111A0ZZZ uses background suppression, v-optics with a specified sensing range of 2–22 mm.
What output and connection does it use?
It provides 1 push-pull pnp/npn output, uses light switching and connects by m8 connector, 3-pin.
Does WTV4FE-213111A0ZZZ support IO-Link?
No IO-Link interface is specified for this exact variant; it uses a conventional switching output.
Request pricing and availability
Send the required quantity, destination and application details so we can confirm WTV4FE-213111A0ZZZ for your order.
Request a quote
